in short

Frege is a C library that is used for superfast image generation of three dimensional spatial data. It was historically developed for air traffic control software – APOI PRIOR radar processing system on 1992.

Ever since Frege has been the cornerstone for all the software solutions developed by R-Systems.

top down

inside out

Real-time superfast


It is a very thin abstract layer of C functions with pointer arguments, which take virtually no time to execute.

Flexible


It is a highly abstract C library, with no limitations. The source code is has also well documented reference, and is open for modification.

Highly reliable


The library was initially written to server mission critical applications, like the Air Traffic Control.

3D


Contrary to common geographical API-s, e.g Google Maps, the spatial objects in Frege include the Z-dimension. Distance from the center of the Earth.

Modular


In addition to various number of data sources, the system also supports simultaneous manipulation of various number of maps and presentation models

Multiple data sources


The library has no limits to the data sources it can use. E.g. fetch data from multiple SQL databases and binary data files simultaneously.

Views

Views are the output of the system - the window into the database, used for:

  • image of the map data
  • results of search

Views render map data via specific presentation model, and deliver the real life medium.

It has the following properties:

  • size and a scale
  • visible object classes
  • presentation model to use, including the presentation parameters
  • output device
    • Display of X Window System
    • Raster image file, eg PNG
    • NULL, used for searching purposes
Presentation model

They define the visual appearance of the map data. One presentation model can be used by multiple maps.

Maps

Maps are collations of spatial and feature objects. Each map has one or more presentation models, which are visualized through views.

Maps are interactive. Change of an object reflects on all the views real-time.

Feature objects

For example: road, city or airplane

  • Geometrical primitive (point, line, area)
  • Class and parameters as defined in data dictionary
  • Links to spatial objects
  • Scale
Spatial objects

The management of hierarchical spatial objects, with 3D location

  • Single point
  • Connected point (e.g. line beginning)
  • Borderline
  • Area
Data dictionary

Data dictionary is the central object of the Frege library. It contains the structure of map objects (spatial, feature) and presentation model.

Attributes

Used to describe the previous objects

Viewing of the map

Initialize the system – fInit

Load the map data - fMapRead

Create the view - fViewCreate, fViewSetDevParam

Load the presentation model - fViewSetLUTMask, fViewSetColorScheme

Draw the map, per request or in loop – fViewSetFocus, fViewDraw

Clean up – fViewDestory, fMapDestory, fEnd
